חיישן אור עד 50 klux
Measuring range 0 to 50 klux
Spectral sensitivity 360 to 760 nm
Maximum spectral sensitivity 555 nm
Signal output 0 to 2 V
Duty cycle <1 second
Power supply via ALMEMO® connector
+5 to +15 V
Fastening 2 screws, M4, in base plate
Cable passage at side
Housing anodized aluminum
Diffuser Plastic
Ball Plastic
Directional characteristic see diagram
Linearity <1%
Absolute error <10%
Nominal temperature 22 ± 2 °C
Operating temperature –20 to +60 °C
Dimensions Ball diameter : 40 mm
Overall height : 76 mm
Weight approx. 100 grams
