Test Force
0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf
Test Range 1HV~2967HV
Test Mode HV/HK
Loading Method Automatic (Loading/Dwell/Unloading)
Turret Automatic Turret
Computer CPU: Intel I3, Memory: 2G, SSD: 32G
CCD Pixel 1.30 Million
Conversion Scale HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N,
HR15T, HR30T, HR45T, HS, HBW
Hardness Reading Indentation Displaying and Automatic Measuring on Touch Screen
Data Output WORD or EXCEL Report with Curve Chart
Objective 10x (Observe), 20x (Measure)
Total Magnification 100x, 200x
Resolution 0.0625μm
Dwell Time 0~60s
Light Source Halogen Lamp
Motorized X‐Y Test Table Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm
Max. Height of Specimen 160mm
Throat 130mm
Power Supply AC220V/50Hz/1Ph, AC110V/60Hz/1Ph
Execute Standard ISO 6507, ASTM E384, JIS Z2244, GB/T 4340.2
Dimension 620×233×635mm, Packing Dimension: 650×380×860mm
Weight Net Weight: 48kg, Gross Weight: 62kg
