Optical System - Colour Corrected Infinity Optical System (CCIS®)
Observation Tube - Binocular head, Siedentopf type
Field of View - 20mm
nosepiece - Quadruple
Illumination - Fixed LED 0.5W
Koehler - Fixed
Interpupillary distance (mm) - 48-75
Inclination - 25° inclined, 360° rotatable (storage saving), 360° swivelling
Eyepieces - N-WF10X/20
Objectives - 4X/0.1 (WD 15.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm),
100X/1.25/S-Oil (WD 0.14mm)
Objective mounting thread - W 4/5" x 1/36" (RMS standard)
Stage - Mechanical stage
Stage size (mm) - 140*135
Travel range X&Y (mm) - 75*50
Accessories included - Immersion oil 5ml, power cord, dust cover, allen key
Dimensions L x W x H (mm) - 282x210x395
Weight (Kg) - 7.7
