מתאים ליישומים בביוטכנולוגיה,
זיהוי פלילי וטכנולוגיה רפואית
זיהוי זיהום בלתי נראה על משטחים ומתאים
לניתוח מרכיבים ואבחון סלולרי
טווח אורכי גל 220 …380 ננומטר
חיישן CMOS עם תאורה אחורית
Spectroscopic splitting methodTransmission grating light splitting
Image resolution 1920X1920
Dynamic range12 bits
Imaging speed 5seconds
Number of Spectral channels1200
Spectral range 400-1000nm
Spectral resolution (FWHM)2.5nm
Slit width 25um
Transmission efficiency≥60%
Stray light level ≤0.5%
Pixel size5.86um*5.86um
Detector type CMOS
Standard lens focal length25mm
Standard lens focal length 25mm
Minimum working distance100mm
Field angle 25°
Minimum exposure time21us
Maximum exposure time 10 seconds
Signal-to-noise ratio 600/1
Data interface USB3.0
Camera lens interfaceC-Mount
PartsUSB3.0 Transmission line
Auxiliary imaging function The auxiliary view camera monitors the shooting area
EyepieceLarge Field of view WF10X(Φ18mm)
Objective lens Long anomaly field achromatic objective (glass without cover) PL 5X/0.12 Long anomaly field achromatic objective (glass without cover) PL L10X/0.25 Long anomaly field achromatic objective (glass without cover) PL L40X/0.60
Long anomaly field achromatic objective (glass without cover) PL L60X/0.75 (spring)
Eyepiece tubeTriocular, tilted 30˚,(built-in polarizer, can be switched)
Episcopic illumination system 6V 20W halogen lamp with adjustable brightness
Fall illuminator with field light bar, aperture light bar, polarizer, (yellow, blue, green) color filter and frosted glass
Focusing mechanism Coarse-adjustable coaxial focusing, coarse-adjustable cell value :2μm, coarse-adjustable elastic, with locking and limiting device
Converter Four holes (inward ball positioning)
Stage Double-layer mechanical mobile (size :185mmX140mm, moving range :75mmX50mm)
