Quick and reliable tensile, compression, bending, shear, peel, loop tack and fatigue cycling on metals, tape, composites, alloys, rigid plastics and films, elastomers, textiles, paper, board and finished products.
Specifications:
Capacity choice: 1,2,5,10,20,50,100,200,500kg optional
Stroke: 850mm(excluding clamp)
Range of speed: 0.1～1000mm/min
Effective testing space: 120mmMAX
Accuracy: ±0.5%
Operation method: Windows operation
Motor: Japan Panasonic servo motor
Optional accessories: stretcher, air clamp
Resolution: 1/250,000
Weight: 80kg
Dimention: (W×D×H)58×58×145cm
Power: 1PH, AC220V, 50/60Hz
Including software "A" Version
PC and stand are not included
