Sensor Size 1.1”
Capture Resolution Info 12MP
Resolution 20X: 0.52μm/pixel
40X: 0.26μm/pixel
80X: 0.13μm/pixel
Scanning Time 20X with 10X objective: 40s
40X with 20X objective: 75s
Scan mode Standard (Real-time autofocus)
High precision (High-precision autofocus)
EDF (Extended depth of field)
Z-stack (Three-dimensional stacking)
Scanning Formats MDS, SVS, JPEG, DICOM, TIFF
Objectives (Ccis®, Din) Plan S-Apochromatic 10X/0.3
Plan Apochromatic 20X/0.75
UC Fluor 40X/0.75*
*equivalent to standard of “S Apo objective 40x”
Slide Capacity 60
Slide Tray 6-slide smart tray
Software DSAssistant, EasyScanner, DSServer
Barcode Support 1D: Interleaved 2 of 5, Code 39, Code 128 - 2D: Data Matrix, QR Code
Computer Included All-in-one PC, Intel(R) Core(TM) i7-10700/16GB RAM,
256GB SSD + 1 TB storage
Recommended Specifications For Scanner PC Intel Core i7-10700, 32GB Memory,
256GB SSD + 1TB SATA Disk, Window 10 Professional 64-bit
