Insulation material Graphite
Dimensions:
External H x W x D(mm)
x 1300 x 1100 2200
Transport weight (kg) 1200
Usable space Volume (litres) 25
H x W x D usable space
without retort (mm) 250 x 250 x 400
H x W x D usable space
with retort (mm) 230 x 230 x 400
Thermal values Tmax vacuum (°C) 2200
-Delta-T between 500 and 1500°C (K)
according to DIN 17052 ± 10
Max. heat-up rate (K/min) 10
Cooling time (h) 6Connecting values
Power (kW) 60 Voltage (V) 400 (3P)
Current (A) 90 3x Series fuse (A) 3x 125
Vacuum (option) Leakage rate - clean,
cold and empty (mbarl/s) 5x10-3
Vacuum range depending on the
pumping unitrough, fine or high
