Tmax furnace incl. tube 1300°C
Tmax at sample 1250°C
Gas flow rate 35 – 370 L/h
Pressure Atmospheric +40 mbar. rel
Furnace dimension (HxWxD):
1460 x 780 x 1500mm
Total furnace weight 650 kg
Volume retort iD 180 x L 500 mm
(125 x 125 x 500 mm)
Maximum sample weight 15 kg
Uniform ± 5 °C and recommended
usable volume[mm]:100 x 100 x 350
Number of heated zones:2
Leakage rate:<5x10E-3 mbar * l/s
Power :15kW
Weight :500kg
Max.heat up rate:600 °C/h
