Flow range 90~2700 mL/min
Speed range 300~3000rpm
Speed resolution 1rpm
Working mode Speed—variable mode, time dispensing
Dispensing time 0.1~9995
Transport limitation of liquid particles particles IDs10pm (recommended pre—filter)
Transmission liquid viscous g200cSt
Analog input signal 0 ~ 5V (Standard), 0 ~10\/, 4 ~ 20mA (Optional)
External control signal 5V, 12V(Standard), 24V (Optional)
Communication RS485 communication, MODBUS protocol
Working environment Working temperature 0 ~ 40°C, relative humidity < 80%
Power supply AC100-240V, 50/60Hz
Power consumption < 150W
IP grade IP31
Dimension (LxWxH) 320x150x237mm
Shell material 30455
Weight 5.5kg
