מתאים ליישומים בביוטכנולוגיה,
זיהוי פלילי וטכנולוגיה רפואית
זיהוי זיהום בלתי נראה על משטחים ומתאים
לניתוח מרכיבים ואבחון סלולרי
טווח אורכי גל 220 …380 ננומטר
חיישן CMOS עם תאורה אחורית
Spectroscopic methodGrating
Image resolution
1920*1920
Dynamic range12 bits
Imaging speed
≤15 seconds
Spectral channels number600
Spectral region
400-700nm
Spectral FWHM2.5nm
Slit width
25um
Transmission efficiency60%
Stray light level
0.5%
Pixel size5.86um*5.86um
Detector type
CMOS
Sensor imaging surface size11.3*7.1mm
Standard lens focal length 25mm
Minimum working distance100mm-∞
Field angle 25°
Minimum exposure time34us
Maximum exposure time 10 seconds
SNR600/1
Data interface USB3.0
Camera lens interfaceC-Mount
Accessories USB3.0
Imaging features With ROI function Single area ROI can be achieved
Auxiliary imaging fealtures Auxiliary framing camera to monitor the shooting area
Power supply modeBuilt-in battery
Host engine size 25.5cm*13.8cm*10.7cm
WeightLess than 2.8KG
Power dissipation 50W
