מתאים ליישומים בביוטכנולוגיה,
זיהוי פלילי וטכנולוגיה רפואית
זיהוי זיהום בלתי נראה על משטחים ומתאים
לניתוח מרכיבים ואבחון סלולרי
טווח אורכי גל 220 …380 ננומטר
חיישן CMOS עם תאורה אחורית
Suitable for applications in biotechnology,
forensics and medical technology
Detect invisible contamination on surfaces and is suitable
for ingredient analysis and cellular diagnostics
220 … 380 nm wavelength range
back-illuminated CMOS sensor
USB 3.1 interface
Different cooling options available
~40 fps @ 2048 x 2048 pixels (max. sensor resolution with passive cooling)
free of periodical calibration of optical path components
Excellent optical imaging performance
designed without moving mechanical parts
Spectroscopic methodGrating
Image resolution
1280*1280
Dynamic range12 bits
Imaging speed 100fps
Spectral channels number680
Spectral region 400-1700nm
Spectral FWHM13nm
Slit width 25um
Transmission efficiency60%
Stray light level
0.5%
Pixel size5um*5um
Detector type InGaAs
Standard lens focal length 16mm
Minimum working distance100mm-∞
Field angle 22.6°
SNR600/1
Data interface USB3.0
Camera lens interfaceC-Mount
Accessories Lens, USB3.0 data cable, power adapter
Imaging features ROI function, can realize multiple area ROI
Auxiliary imaging fealtures Auxiliary framing camera to monitor the shooting area
Power supply modeBuilt-in battery
