מתאים ליישומים בביוטכנולוגיה,
זיהוי פלילי וטכנולוגיה רפואית
זיהוי זיהום בלתי נראה על משטחים ומתאים
לניתוח מרכיבים ואבחון סלולרי
טווח אורכי גל 220 …380 ננומטר
חיישן CMOS עם תאורה אחורית
Spectroscopic methodGrating
Image resolution
640*640
Dynamic range14 bits
Imaging speed ≤5 seconds
Spectral channels number512
Spectral region 900-1700nm
Spectral FWHM6nm
Slit width 25um
Transmission efficiency60%
Stray light level
0.5%
Pixel size15um*15um
Detector type InGaAs
Sensor imaging surface size7.68*9.6mm
Standard lens focal length 25mm
Minimum working distance100mm-∞
Field angle 17°
Minimum exposure time50us
Maximum exposure time 1 seconds
SNR600/1
Data interface USB3.0
Camera lens interfaceC-Mount
Accessories USB3.0
Imaging features With ROI function Single area ROI can be achieved
Auxiliary imaging fealtures Auxiliary framing camera to monitor the shooting area
Power supply modeBuilt-in battery
Host engine size 33.5cm*18.2cm*14.3cm
WeightLess than 5.3KG
Power dissipation 50W
