מתאים ליישומים בביוטכנולוגיה,
זיהוי פלילי וטכנולוגיה רפואית
זיהוי זיהום בלתי נראה על משטחים ומתאים
לניתוח מרכיבים ואבחון סלולרי
טווח אורכי גל 220 …380 ננומטר
חיישן CMOS עם תאורה אחורית
Spectroscopic methodTransmission grating
Image resolution 1280X1280
Dynamic range12 bits
Imaging speed 10s
Spectral channel1024
Spectral range 900-1700nm
Spectral resolution (FWHM)6nm
Slit width 25um
Transmission efficiency> 60%
Stray light level < 0.5%
Pixel size5um*5um
Detector type InGaAs
Sensor imaging surface size7.68mm*9.6mm
Standard lens focal length 25mm
Minimum working distance150mm
Field angle 14.5°
Minimum exposure time1us
Maximum exposure time 10 seconds
SNR600/1
Data interface start
Camera lens interfaceC-Mount
Attachment USB3.0 transmission line
Imaging features Have ROI capability-Multiple regional ROIs can be achieved
Auxiliary imaging fealtures Auxiliary view camera to realize the monitoring of the shooting area
Power supply modeBuilt-in battery
dimension: Length x width x height :24.8cm*14.5cm*14.5cm
Weight2535g
Power dissipation 50W
