מערכות פרופילינג לקווי ייצור למדידת לחות ומשקל ציפוי

Power90-260VA
Ambient Temperature0 – 50°C (32 – 120°F) with air cooling up to 80°C (160°F)
Scanning Frame Outputs3X 4-20mA Selectable Sources; Live NIR Value; Scan NIR Average Values; Live Temperature Scan & Scan Temperature Average Value
Scanning Frame InputsWeb Break; Web Length; Cooling Air; Sensor Window Purge
Moisture RangeMin. 0.1%, Max. 95%
Moisture Accuracy+/- 0.1%
Coatings RangeMin. 0.1 GSM, Max. 250 GSM
Coatings Accuracy+/- 0.1 gr/m
Repeatability+/- 0.1%
